Holding Fixture Installation for Generic Unit Repair 1998
Tools Required
•
J 8763-B
Holding Fixture
•
J 3289-20
Holding Fixture Base
Install
J 8763-B
onto the transmission assembly.
Install the transmission assembly and
J 8763-B
into
J 3289-20
and use the fixture pin to lock the holding fixture in place.
