Makes 🢒 Pontiac 🢒 2006 🢒 Torrent 🢒 Engine 🢒 Engine Controls - 3.4L 🢒 Rear Wheelhouse Panel Liner Replacement

Rear Wheelhouse Panel Liner Replacement for Pontiac Torrent 2006

Removal Procedure

    Object Number: 1360930 Size: SH
  1. Remove the rear wheelhouse liner push-in retainers.
  2. Remove the rear wheelhouse liner from the vehicle.

Installation Procedure

    Object Number: 1360930 Size: SH
  1. Position the rear wheelhouse liner to the vehicle.
  2. Install the push-in retainers.
